Nissan Patrol Y61 LWB Long Arm chassis

Beschrijving

Nissan Patrol Y61 LWB Long Arm chassis

Discover the ultimate upgrade for your Nissan Patrol Y61 LWB with this Long Arm chassis, designed for maximum durability and performance. This chassis is manufactured from high-quality, hot-dip galvanised steel and offers a perfect fit to your vehicle’s original mounting points. Thanks to its advanced construction, the chassis is ideally suited for off-road use, restoration or complete replacement of the original body structure.

Key benefits

• Steering column bracket on the left-hand side for optimum steering.
• Aligns precisely with the manufacturer’s mounting points for easy installation.
• Additional mounting points under the chassis for accessories and a second fuel tank.
• Reinforced front and rear side members, as well as the spring housings and Panhard rod brackets.
• Reinforced front bumper bracket and LongArm control arm bracket for extra strength.
• Fitted with holes to facilitate cleaning of the chassis interior and the fitting of sills.
• Bolt-on engine mounts allow engines to be swapped without damaging the corrosion protection (suitable for various engine types, such as SWAP M57/M60/LS/JZ/UZ/OM606).
• Lowered beam position for greater suspension travel and optimum suspension performance with a suspension lift.
• Threads in thick-walled sleeves, which can be re-tapped if damaged.

Technical specifications

• Material: Hot-dip galvanised steel
• Compatibility: Nissan Patrol Y61 LWB
• Assembly: Precise fit at the original mounting points

This chassis is supplied complete and is ready for assembly straight away. Please note: engine mounts are not included and must be ordered separately. The delivery time is approximately 3 months following payment of a deposit of at least 30%. Transport costs will be finalised one week before the end of production.

Application

Ideal for rebuilding, restoring or upgrading your off-road vehicle. Choose reliability, robustness and a long service life with this high-quality chassis for the Nissan Patrol Y61 LWB Long Arm.
